Input types: Thermocouple - K, E, J, T, B, R, S, N
Output types: current or voltage with different ranges
Possibility to make a range of inputs / outputs on a special order.
Wire connection | M3 screw terminals |
---|---|
Separation | Input / Output / Power |
Dielectric strength | Power up DC: 2000V AC With AC power: 1500V AC |
Ranges selection | To be set when ordering |
Double Exit | Yes |
Power | AC / DC | tr >
Operating temperature | - 5 to + 55 ° C | Mount | DIN Rail |
Dimensions | 45x41x97mm |
