Производител: M-SYSTEM

M2du - ток захранване на цикъла

  • M2DU

M2DU is a 10 ... 50mA DC loop power supply.


Features

  • It supplies the 10 ... 50mA DC current loop
  • Mounting socket for of each model - enables easy assembly / disassembly and quick conversion of converters without interfering with the wiring.
  • Short-circuit protection
  • Power on the output - 24 V DC
  • AC power / DC

Input: 10… 50mA DC
Output: 1… 5V DC
Power supply: AC / DC


< / tr>

Изпратете запитване

Интересувате ли се от този продукт? Имате ли нужда от допълнителна информация или индивидуални цени?

Свържете се с нас
ПОИСКАЙТЕ ПРОДУКТА close
Благодарим ви, че изпратихте съобщението си. Ние ще отговорим възможно най-скоро.
ПОИСКАЙТЕ ПРОДУКТА close
Преглед

Добави към списъка с желания

Трябва да сте влезли

M2DU is a 10 ... 50mA DC loop power supply.


Features

  • It supplies the 10 ... 50mA DC current loop
  • Mounting socket for of each model - enables easy assembly / disassembly and quick conversion of converters without interfering with the wiring.
  • Short-circuit protection
  • Power on the output - 24 V DC
  • AC power / DC

Input: 10… 50mA DC
Output: 1… 5V DC
Power supply: AC / DC


Wire connection Terminals M3 screw screws
Separation Input / Output / Power
Dielectric strength DC power: 2000V AC
AC power : 1500V AC
Select r ranges None
Double exit None
Power AC / DC
Operating Temperature - 5 to +55 ° C
Mounting DIN rail
Dimensions 23x76x124mm
< / tr>
Коментари (0)

бюлетин

Абонирайте се за нашия бюлетин, за да получавате информация за промоции и нови продукти в нашия магазин.

попитайте за продукта
Wire connection Terminals M3 screw screws
Separation Input / Output / Power
Dielectric strength DC power: 2000V AC
AC power : 1500V AC
Select r ranges None
Double exit None
Power AC / DC
Operating Temperature - 5 to +55 ° C
Mounting DIN rail
Dimensions 23x76x124mm
