Производител: ALRE

Термостати за помещения с висока влажност

Application

Control and monitoring of temperatures of certain open spaces, for example, driveways or damp rooms (greenhouses, sheds, warehouses and basements, garages, etc.).

Technical data

Housing colour: grey (lower part like RAL 7016, upper part like RAL 7035)
Ambient temperature: −20…+60 °C
Permissible atmospheric humidity: Max. 95% rel. humidity, non-condensing
Operating voltage: 230 VAC, 50 Hz
Max. switching current: heating (terminal 3) 10 (4) A,
cooling (terminal 1) 5 (2) A
Max. switching voltage: 230 VAC, 50 Hz
Min. switching voltage: 230 VAC, 50 Hz
Switching element: bimetallic contact
Control range: −20…+30 °C
Hysteresis: approx. 2 K at a temperature change of max. 4 K/h
Electrical connection: screw-type terminals 0.12 mm² to 2.5 mm²
Mounting/attachment: wall mounting
Protection rating: IP 65
Protection class: II
Safety and EMC: according to DIN EN 60730
Sensor: bimetal
Function type: TW (temperature monitor
General features: thermal feedback, internal setting, scale: degrees Celsius
Type Item no. Features PG
PTR 40.000 A201410 switching contact changeover switch (toggler), control function heating or cooling, viewing window II
