Výrobce: Kerafol

Keralpor S

Keralpor S

Alumina 92% + 8% Zirconium

Keralpor S is a sinter that can be used to sinter a variety of metal injection molding (MIM) products and materials. The advantage of this zirconia cured porous alumina is its good thermal shock resistance and high mechanical strength. Thanks to the porous structure (32%), adhesion of the sintered part is prevented.

Due to the porous structure of the sinter, adhesion of unfired ceramics lying on it can be avoided. Customers use Keralpor S especially for the debinding and sintering of stainless steel MIM products and for blast furnace cooling processes.

All sizes are available in thickness
1,6 mm!

Ask for dimensions tailored to your needs and we will quickly create your Keralpor S.

Typical features Unit Value
Color - biały
Gross density g/cm3 2,7
Surface roughness Ra µm 0,7
Flexural strength MPa >100
Bend % < 0,3
Porosity Vol.% 32
Dimensions mm 10 x 10 do 310 x 310
Thickness mm 1,6
Main ingredients % 92% Al2O3 + 8% ZrO2
Maximum operating temperature Tmax 1400°C

Benefits

  • surface free of dust and particles
  • homogeneous distribution of pores throughout the sinter
  • very good mechanical strength despite high porosity
  • water jet or laser cutting is possible
  • good thermal shock resistance
  • good flatness and surface quality
  • it is possible to adjust the size of the sinter to the needs
  • gases can diffuse freely through the sinterer

Usage

  • sintered plate for metal injection molding (MIM) parts.
  • sintered plate for ceramic injection molding (CIM) parts.
  • sintered plate for high requirements of thermal shock resistance
