SERIES |
ST 73 |
ST 87 |
---|---|---|
Density |
0,98 |
0,96 |
Hardness |
73 sh A |
87 sh A |
Withstand for breaking |
8,3 MPa |
15,9 Mpa |
Elongation after breaking |
375% |
530% |
Maximum operating temperature |
+125"C |
+125"C |
Dielectric withstand |
16 KV/mm |
16 KV/mm |
Min. temperature |
- 40°C |
- 40°C |
Module 100% |
3.2Mpa |
6.9Mpa |
Standards |
ISO 3795 |
ISO 3795 |
Specific properties |
Good resistance for flame, oils. Good mechanical characteristics. |
Good resistance for flame, oils. Good mechanical characteristics. |
Colour |
black |
black |
Diameter and length on a spool | Ø | Length on a spool | For higher diameters please contact us |
---|---|---|---|
0,5 x 1,2 | 500m | ||
1 x 1,8 | 500m | ||
2 x 2,8 | 500m | ||
3 x 3,8 | 500m | ||
4 x 4,8 | 500m | ||
5 x 6 | 250m | ||
6 x 7 | 250m | ||
7 x 8 | 250m | ||
8 x 9 | 250m | ||
9 x 10 | 100m | ||
10 x 11 | 100m |
