Input types: RTD - JPt 100 (JIS'89), Pt 100 ( JIS'89), Pt 100 (JIS'97, IEC), Pt 50Ω (JIS'81), Ni 508.4Ω, Pt 1000, Ni 100, Cu 10 @ 25 ° C
Types of outputs: current or voltage with different ranges
Possibility to make a range of inputs / outputs on a special order.
Wire connection | M3 screw terminals |
---|---|
Separation | Input / Output / Power |
Dielectric strength | DC: 2000V AC AC: 1500V AC |
Ranges selection | Configurable via PC |
Double Output | None |
Power | AC / DC td> |
Operating Temperature | - 5 to + 55 ° C |
Mounting | DIN rail |
Dimensions | 29.5x83x124mm |
