Symbol | Elektrisches Schaltbild |
---|---|
H | ![]() |
D | ![]() |
Typ | VRRm [V] | IDC [A] | VISO [V] | IFSM [A] | VFM [V] | trr [µs] max | Gehäuse |
---|---|---|---|---|---|---|---|
RM1200DB-34S | 1700 | 1200 | 4000 | 20800 | 1,9 | 1 | RM4 |
RM1800HE-34S | 1700 | 1800 | 6000 | 9600 | 2,9 | 1,8 | RM1 |
RM1200HA-50S | 2500 | 1200 | 6000 | 9600 | 2,9 | 1,2 | RM2 |
RM400DY-66S | 3300 | 400 | 6000 | 3200 | 3,5 | 1,2 | RM3 |
RM600DY-66S | 3300 | 600 | 6000 | 4800 | 3,5 | 1,2 | RM3 |
RM1200HA-66S | 3300 | 1200 | 6000 | 9600 | 3,3 | 1,2 | RM2 |
RM1200DB-66S | 3300 | 1200 | 6000 | 9600 | 2,9 | 0,8 | RM3 |
RM1200DG-66S | 3300 | 1200 | 10200 | 9600 | 2,9 | 0,7 | RM5 |
RM1200HE-66S | 3300 | 1200 | 6000 | 9600 | 3,2 | 1,4 | RM1 |
RM600HE-90S | 4500 | 600 | 6000 | 4800 | 4,8 | 1,8 | RM1 |
RM900DB-90S | 4500 | 900 | 6000 | 6400 | 4,2 | 0,9 | RM3 |
RM200DG-130S | 6500 | 200 | 10200 | 9600 | 4,0 | 1,0 | RM4 |
RM400DG-130S * | 6500 | 400 | 10200 | in Bearbeitung | |||
RM600DG-130S | 6500 | 600 | 10200 | 4800 | 3,6 | 1,0 | RM6 |
Hinweis:
* Module in der Entwicklungsphase
Gehäuse - RM1 ![]() | Gehäuse - RM3 ![]() |
Gehäuse - RM2 ![]() | Gehäuse - RM5 ![]() |
Gehäuse - RM4 ![]() | |
Gehäuse - RM6 ![]() |
Interessieren Sie sich für dieses Produkt? Benötigen Sie zusätzliche Informationen oder individuelle Preise?
