Technical data
Operating temperature range: -25oC ÷70oC
Tolerance: ±10%
Type | UN [VDC] |
Capacitance [µF] |
Us [V] |
Imax A |
dv/dt V/us |
L [nH] |
Rs [mΩ] |
---|---|---|---|---|---|---|---|
LNK-P7X-1200-70 |
700 | 1200 | 1400 | 180 | 10 | 30 | 0.22 |
LNK-P7X-750-90 |
900 | 750 | 1800 | 155 | 10 | 30 | 0.28 |
LNK-P7X-600-100 |
1000 | 600 | 2000 | 150 | 13 | 30 | 0.32 |
LNK-P7X-500-110 |
1100 | 500 | 2200 | 145 | 14 | 30 | 0.35 |
LNK-P7X-400-125 |
1250 | 400 | 2500 | 140 | 17 | 30 | 0.38 |
LNK-P7X-300-145 |
1450 | 300 | 2900 | 130 | 19 | 30 | 0.44 |
LNK-P7X-200-180 |
1800 | 200 | 3600 | 120 | 24 | 30 | 0.53 |
Interessieren Sie sich für dieses Produkt? Benötigen Sie zusätzliche Informationen oder individuelle Preise?
Sie müssen eingeloggt sein
Technical data
Operating temperature range: -25oC ÷70oC
Tolerance: ±10%
Type | UN [VDC] |
Capacitance [µF] |
Us [V] |
Imax A |
dv/dt V/us |
L [nH] |
Rs [mΩ] |
---|---|---|---|---|---|---|---|
LNK-P7X-1200-70 |
700 | 1200 | 1400 | 180 | 10 | 30 | 0.22 |
LNK-P7X-750-90 |
900 | 750 | 1800 | 155 | 10 | 30 | 0.28 |
LNK-P7X-600-100 |
1000 | 600 | 2000 | 150 | 13 | 30 | 0.32 |
LNK-P7X-500-110 |
1100 | 500 | 2200 | 145 | 14 | 30 | 0.35 |
LNK-P7X-400-125 |
1250 | 400 | 2500 | 140 | 17 | 30 | 0.38 |
LNK-P7X-300-145 |
1450 | 300 | 2900 | 130 | 19 | 30 | 0.44 |
LNK-P7X-200-180 |
1800 | 200 | 3600 | 120 | 24 | 30 | 0.53 |
