Fotos dienen nur zu Informationszwecken.
please use latin characters
Type | IF((AV)/TC [A/°C] |
URRM/VRRM [V] |
IFSM [A] |
I2t [A2s] |
Rthjc [°C/W] |
Rthcs [°C/W] |
Casing |
---|---|---|---|---|---|---|---|
QRS0620T30 | 66/80 | 600 | 2,8/200 | 110 | 0,35 | 0,04 | 15 |
QRS0640T30 | 128/80 | 600 | 2,8/400 | 110 | 0,18 | 0,04 | 15 |
QRS0660T30 | 194/80 | 600 | 2,8/600 | 110 | 0,12 | 0,04 | 15 |
QRS0680T30 | 267/80 | 600 | 2,8/800 | 110 | 0,09 | 0,04 | 15 |
QRS061K001 | 420/80 | 600 | 2,8/1000 | 150 | 0,07 | 0,04 | 18 |
QRS1220T30 | 88/80 | 1200 | 3,5/200 | 250 | 0,18 | 0,04 | 15 |
QRS1240T30 | 180/80 | 1200 | 3,5/400 | 250 | 0,09 | 0,04 | 15 |
QRS1260T30 | 276/80 | 1200 | 3,5/600 | 250 | 0,06 | 0,04 | 15 |
QRS1420T30 | 84/80 | 1400 | 3,8/200 | 300 | 0,18 | 0,04 | 15 |
QRS1440T30 | 169/80 | 1400 | 3,8/400 | 300 | 0,09 | 0,04 | 15 |
QRS1460T30 | 258/80 | 1400 | 3,8/600 | 300 | 0,06 | 0,04 | 15 |
Drawing 15 dimensions [mm]
|
Drawing 18 dimensions [mm]
|
---|---|
![]() |
![]() |
