Sie müssen eingeloggt sein
-
zurückX
-
Komponenten
-
-
Category
-
Halbleiter
- Dioden
- Thyristoren
-
Elektroisolierte Module
- Elektroisolierte Module | VISHAY (IR)
- Elektroisolierte Module | INFINEON (EUPEC)
- Elektroisolierte Module | Semikron
- Elektroisolierte Module | POWEREX
- Elektroisolierte Module IXYS
- Elektroisolierte Module | POSEICO
- Elektroisolierte Module ABB
- Elektroisolierte Module | TECHSEM
- Gehen Sie zur Unterkategorie
- Brückengleichrichter
-
Transistoren
- Transistoren | GeneSiC
- SiC-MOSFET-Module | Mitsubishi
- SiC-MOSFET-Module | STARPOWER
- ABB SiC-MOSFET-Module
- IGBT-Module | MITSUBISHI
- Transistormodule | MITSUBISHI
- MOSFET-Module von MITSUBISHI
- Transistormodule | ABB
- IGBT-Module | POWEREX
- IGBT-Module | INFINEON (EUPEC)
- Halbleiterkomponente aus Siziliumkarbid
- Gehen Sie zur Unterkategorie
- Treiber
- Leistungsblöcke
- Gehen Sie zur Unterkategorie
-
Strom- und Spannungswandler von LEM
-
Stromwandler von LEM
- Stromwandler mit geschlossener Rückkopplungsschleife (C / L)
- Stromwandler mit offener Rückkopplungsschleife (O / L)
- Stromwandler mit unipolarer Spannung
- Wandler in der Eta-Technologie
- Hochgenaue Stromwandler der Serie LF xx10
- Stromwandler der Serie LH
- HOYS und HOYL - zur direkten Montage auf einer Leiterschiene
- Stromwandler in der SMD-Technologie der Serien GO-SME und GO-SMS
- AUTOMOBIL-Stromwandler
- Gehen Sie zur Unterkategorie
- Spannungswandler | LEM
- Präzisionsstromwandler | LEM
- Gehen Sie zur Unterkategorie
-
Stromwandler von LEM
-
Passive Elemente (Kondensatoren, Widerstände, Sicherungen, Filter)
- Widerstände
-
Sicherungen
- Miniatursicherungen für elektronische Schaltungen der Serien ABC und AGC
- Schnelle Röhrensicherungen
- Zeitverzögerungssicherungen mit GL / GG- und AM-Eigenschaften
- Ultraschnelle Sicherungseinsätze
- Britische und amerikanische schnelle Sicherungen
- Schnelle europäische Sicherungen
- Traktionssicherungen
- Hochspannungs-Sicherungseinsätze
- Gehen Sie zur Unterkategorie
-
Kondensatoren
- Kondensatoren für Motoren
- Elektrolytkondensator
- Island Filmkondensatoren
- Leistungskondensatoren
- Kondensatoren für Gleichstromkreise
- Kondensatoren zur Leistungskompensation
- Hochspannungskondensatoren
- Induktionsheizkondensatoren
- Impulskondensatoren
- DC LINK-Kondensatoren
- Kondensatoren für AC / DC-Schaltungen
- Gehen Sie zur Unterkategorie
- Entstörungsfilter
- Superkondensatoren
-
Überspannungsschutz
- Überspannungsableiter für HF-Anwendungen
- Überspannungsableiter für Bildverarbeitungssysteme
- Überspannungsableiter für Stromleitungen
- Überspannungsableiter für LED
- Überspannungsableiter für die Photovoltaik
- Überspannungsableiter für Wägesysteme
- Überspannungsableiter für den Feldbus
- Gehen Sie zur Unterkategorie
- Gehen Sie zur Unterkategorie
-
Relais und Schütze
- Theorie der Relais und Schütze
- Dreiphasen-Halbleiterrelais AC
- Halbleiterrelais DC
- Regler, Steuerungen und Zubehör
- Sanftstarter und Schaltschütze
- Elektromechanische Relais
- Schütze
- Drehschalter
-
Einphasen-Halbleiterrelais AC
- Einphasen-Wechselstrom-Halbleiterrelais, Serie 1 | D2425 | D2450
- Einphasige AC-Halbleiterrelais der Serien CWA und CWD
- Einphasen-Wechselstrom-Halbleiterrelais der Serien CMRA und CMRD
- Einphasen-Wechselstrom-Halbleiterrelais, PS-Serie
- Doppel- und Vierfach-Wechselstrom-Halbleiterrelais, Serie D24 D, TD24 Q, H12D48 D.
- 1-phasige Festkörperrelais, gn-Serie
- Einphasige Wechselstrom-Halbleiterrelais, Serie ckr
- Einphasen-Wechselstromrelais der ERDA- UND ERAA-SERIE für die DIN-Schiene
- Einphasige Wechselstromrelais für 150A Strom
- Doppelte Halbleiterrelais mit integriertem Kühlkörper für eine DIN-Schiene
- Gehen Sie zur Unterkategorie
- Einphasen-Halbleiterrelais AC für Leiterplatten
- Interface-Relais
- Gehen Sie zur Unterkategorie
- Induktive Komponente
- Radiatoren, Varistoren, Thermoschütze
- Ventilatoren
- Klimaanlagen, Ausrüstung für Schaltschränke, Industriekühler
-
Batterien, Ladegeräte, Pufferstromversorgungen und Wechselrichter
- Batterien, Ladegeräte - theoretische Beschreibung
- Lithium-Ionen-Batterien. Kundenspezifische Batterien. Batteriemanagementsystem (BMS)
- Batterien
- Ladegeräte und Zubehör
- USV-Notstromversorgung und Pufferstromversorgung
- Konverter und Zubehör für die Photovoltaik
- Energiespeicher
- Brennstoffzellen
- Lithium-Ionen-Batterien
- Gehen Sie zur Unterkategorie
-
Automation
- Futaba Drone Parts
- Grenzschalter, Microschalter
- Sensoren, Wandler
-
Pyrometer
- Infrarot-Temperatursensor, kabellos, wasserdicht, IR-TE-Serie
- Infrarot-Temperatursensor, kabellos, IR-TA-Serie
- Infrarot-Temperatursensor, kabellos, IR-H-Serie
- Ein schnelles stationäres Pyrometer in einem sehr kleinen IR-BA-Gehäuse
- Lichtleiter-Temperatursensoren, IR-FA-Serie
- Das stationäre Pyrometer der IR-BZ-Serie
- Gehen Sie zur Unterkategorie
- Zähler, Zeitrelais, Einbaumessgeräte
- Industrielle Schutzausrüstung
- Licht- und Signalentechnik
- Infrarot-Kamera
- LED-Anzeigen
- Taster, Schalter und Zubehör
-
Datenerfassung und Datenlogger
- Temperaturschreiber mit Display und Textdruck AL3000
- Digitale Temperaturschreiber mit LCD Display KR 2000-Serie
- Sicherheitstemperaturwächter KR 5000
- Temperatur / Feuchtigkeit Hand-Meter mit Datenlogger HN-CH-Serie
- Messdatenerfassung und Datenlogger Zubehör
- Kompakter Bildschirmschreiber 71VR1
- Sicherheitstemperaturwächter KR 3000-Serie
- PC-Datenerfassung R1M-Serie
- PC-Datenerfassung R2M-Serie
- PC-Datenerfassung, 12 universelle isolierte Eingänge, Typ RZMS-U9
- PC-Datenerfassung, 12 universelle isolierte Eingänge, USB, RZUS-Serie
- Gehen Sie zur Unterkategorie
- Gehen Sie zur Unterkategorie
-
Adern, Litzen, Schutzhüllen, Flexible Verbingungen
- Drähte
- Litzen
-
Kabel für spezielle Anwendungen
- Verlängerungskabel und Kompensations
- Kabel für Thermoelemente
- Die Verbindungsdrähte zu czyjnków PT
- Mehradrige Kabel Temp. -60 ° C bis + 1400 ° C
- SILICOUL Mittelspannungskabeln
- Zündkabel
- Heizleitungen
- Einadriges Temp. -60 ° C bis + 450 ° C
- Zugbegleiter
- Heizleitungen im Ex
- Gehen Sie zur Unterkategorie
- Schläuche
-
Geflochtene Kabel
- Zöpfe flach
- Zöpfen Runde
- Sehr flexible Geflecht - flach
- Sehr flexible Geflecht - Rund
- Kupfergeflecht zylindrischen
- Kupfergeflechtschirm und zylindrischer
- Flexible Massebänder
- Geflechte zylindrischen verzinkt und Edelstahl
- PVC-isolierte Kupferlitzen - Temperatur 85 ° C
- Flach geflochtene Aluminium
- Connection Kit - Zöpfe und Röhren
- Gehen Sie zur Unterkategorie
- Leitungen und Sonstiges für Traktion
- Crimpverbinder
- Flexible isolierte Kupferschienen
- Mehrschichte flexible Kupferschienen
- Kabelrohre, Kabelkanäle und Kabelführung
- Kabelschutzschlauchsysteme
- Gehen Sie zur Unterkategorie
- Alle Kategorien
-
Halbleiter
-
-
- Lieferanten
-
Applications
- AC- und DC-Antriebe (Wechselrichter)
- Ausrüstung für Verteilungs-, Steuerungs- und Telekommunikationsschränke
- Bergbau, Metallurgie und Gründung
- CNC-Werkzeugmaschinen
- Energy bank
- HLK-Automatisierung
- Induktionsheizung
- Industrielle Automatisierung
- Industrielle Automatisierung
- Industrielle Schutzvorrichtungen
- Komponenten für explosionsgefährdete Bereiche (EX)
- Maschinen zum Tiefziehen von Kunststoffen
- Maschinen zum Trocknen und Verarbeiten von Holz
- Motoren und Transformatoren
- Schweißmaschinen und Schweißmaschinen
- Straßenbahn- und Bahntraktion
- Temperaturmessung und -regelung
- Temperaturmessung und -regelung
- USV- und Gleichrichtersysteme
-
Installation
-
-
Montaż urządzeń
- Schaltschränkebau
- Design und Montage von Schränken
- Installation von Stromversorgungssystemen
- Komponenten
- Maschinen, die auf Bestellung gebaut werden
- F&E-Forschungs- und Entwicklungsarbeiten
-
Produktionsprozessen Messungsanlagen
- Dioden und Thyristoren Messungsanlagen
- Schaltungen Messungsanlagen
- Varistor- und Überspannungsableiter-Tester
- Messungsanlagen für Kfz-Sicherungen
- Qr Sperrverzögerungsladung Messungsanlagen
- FD-Serie Schaltungen Rotorentester
- Audit-Messungsanlagen der Fehlerstromschutzschalter
- Tester für Kalibrierung der Relais
- Anlage für Video Qualitätskontrollsysteme
- Hochstrom-Thyristorschalter
- Maschenbruch-Tester
- Gehen Sie zur Unterkategorie
- Alle Kategorien
-
-
-
Inductors
-
-
Modernizacja induktorów
- Reparatur gebrauchter Induktivitäten
- Modernisierung von Induktoren
-
Produktion neuer Induktoren
- Härten von Kurbelwellen
- Aushärten der Bandsägezähne
- Erwärmung der Elemente vor dem Verkleben
- Härtung von Laufbahnen von Radnabenlagern für Kraftfahrzeuge
- Härtung der Antriebsgetriebekomponenten
- Härten von Stufenwellen
- Erwärmung in Kontraktionsfugen
- Scan-Härtung
- Weichlöten
- Knüppelheizungen
- Gehen Sie zur Unterkategorie
- Wissensbasis
- Alle Kategorien
-
-
-
Induktionsgeräte
-
-
Urządzenia indukcyjne
-
Generatoren für Induktionserwärmung
-
Ambrell Induktionsheizgeneratoren
- Generatoren: Leistung 500 W, Frequenz 150-400 kHz
- Generatoren: Leistung 1.2 - 2.4 kW, Frequenz 150 - 400 kHz
- Generatoren: Leistung 4.2 - 10 kW, Frequenz 150 - 400 kHz
- Generatoren: Leistung 10 - 15 kW, Frequenz 50 - 150 kHz
- Generatoren: Leistung 30-45 kW, Frequenz 50-150 kHz
- Generatoren: Leistung 65-135 kW, Frequenz 50-150 kHz
- Generatoren: Leistung 180-270 kW, Frequenz 50-150 kHz
- Generatoren: Leistung 20-35-50 kW, Frequenz 15-45 kHz
- Generatoren: Leistung 75-150 kW, Frequenz 15-45 kHz
- Generatoren: Leistung 200-500 kW, Frequenz 15-45 kHz
- Generatoren: Leistung 20-50 kW, Frequenz 5-15 kHz
- Gehen Sie zur Unterkategorie
- Denki Kogyo Induktionsheizungsgeneratoren
-
JKZ Induktionsheizungsgeneratoren
- Generatoren der CX-Serie, Frequenz: 50-120 kHz, Leistung: 5-25 kW
- Generatoren der SWS-Serie, Frequenz: 15-30 kHz, Leistung: 25-260 kW
- Generatoren (Öfen) zum Formen und Schmieden der MFS-Serie, Frequenz: 0,5-10 kHz, Leistung: 80-500 kW
- MFS-Schmelzöfen, Frequenz: 0,5-10 kHz, Leistung: 70-200 kW
- Generatoren der UHT-Serie, Frequenz: 200-400 kHz, Leistung: 10-160 kW
- Gehen Sie zur Unterkategorie
- Lampengeneratoren für Induktionsheizung
- Himmelwerk Induktionsheizungsgeneratoren
- Gehen Sie zur Unterkategorie
-
Ambrell Induktionsheizgeneratoren
- Reparaturen und Modernisierung
- Peripheriegeräte
-
Applikationen
- Medizinische Anwendungen
- Automobilindustrie Applikationen
- Löten
- Hartlöten
- Hartlöten von Aluminium
- Löten von magnetischen Edelstahlwerkzeugen
- Präzisionslöten
- Löten unter Atmosphäre
- Löten von Kühlkörperkappen aus Messing und Stahl
- Löten von Sintercarbiden
- Löten der Kupferspitze und des Drahtes
- Gehen Sie zur Unterkategorie
- Wissensbasis
- Alle Kategorien
-
Generatoren für Induktionserwärmung
-
-
-
Service
-
-
asd
- Wartung von Brauchwasserkühlern und Klimaanlagen
- Reparaturen und Modernisierung von Maschinen
- Reparatur der Leistungselektronik und elektonischen und automatischen Vorrichtungen
- Hochspannungsnetzteile für Elektrofilter
- Industriedrucker und Etikettierer
- Certyfikaty / uprawnienia
- Alle Kategorien
-
-
- Kontakt
- Zobacz wszystkie kategorie
Fotos dienen nur zu Informationszwecken.
please use latin characters
EINFÜHRUNG - RELAIS UND SCHÜTZE
Solid State Relays
Solid State Relays (SSRs) are components used to control the current load using a semiconductor controlled by a separated electronic circuit. Galvanic separation takes place by means of an optoelectronic element such as a diode emitting infrared radiation, a photodiode, phototransistor, photothyristor or phototriac. In the rest state of the relay, when no current flows through the LED in the input circuit, the optoelectronic element remains switched off and its surrogate resistance is very large. After activating the diode, the photoelement is irradiated and it starts to conduct the switching load circuit. Such a solution allows to significantly increase the switching off frequency, eliminates the phenomenon of electric arc and enables to obtain a lifetime of 109.
Block diagram of a Solid State Relay
Depending on the type, the relay may be switched on by supplying the DC input voltage (from 3V to 32V) or alternating voltage (from 90V to 280V at 50Hz) to the input circuit. There is also the possibility of triggering the relay current. Depending on the purpose, they are built to switch on constant and alternating currents. There are also three-phase relays used, for example, for switching three-phase electric motors.
Types and application
Relays switching on at "zero" voltage – conduction occurs when the supply voltage is zero. Thanks to such a solution, it gradually builds up without causing radio interference. Used to control inductive and resistive loads (resistance heaters, bulbs). | |
Relays switching on "immediately" – the moment of switching on takes place immediately after applying the control voltage. This type of control is intended for solutions where a short response time is required. | |
Relays switching on the voltage at the "peak" - the relay is activated when the peak power supply voltage is reached. Used for strongly inductive loads (transformers). | |
Analog switching relays – controlled by an analog signal (0-10V DC or 4-20mA DC). Used for smooth control of light intensity, heating, etc. |
Parameters characterizing Solid State Relays:
Input circuit:
- control voltage range - voltage range supplied to the input, in which the relay remains switched on (eg: 3-32VDC, 9-280VAC),
- input current range - determines the maximum input current for the relay on and off state,
- switch-on and switch-off time - time elapsed since the control signal is supplied / disconnected to the full enable/disable of the relay.
Output circuit:
- load voltage range - voltage range supplied to the output terminals,
- maximum voltage - maximum permissible value of overvoltage in the power supply network that does not damage the relay,
- load current - maximum permissible value of current flowing in the output circuit,
- maximum unique overload current - maximum value of the current pulse with the duration of one half of the sinusoid,
- maximum I2 t - Joula integral value, used in the selection of fuses.
Useful parameters:
- insulation voltage – effective value of the mains voltage which can occur between the input and output terminals of the relay,
- insulation resistance – the minimum value of the resistance measured using a 500V constant current signal,
- capacity between input and output – measured between input and output terminals,
- ambient temperature range during operation.
Relay cooling
The lifetime of Solid State Relay is virtually unlimited, provided that they are properly cooled. Therefore, special attention should be paid to the selection of the heat sink, use thermal grease and ensure adequate air circulation. A good solution is to mount the relay with a heat sink on the DIN rail, leaving around free space.
Relay protection
Another important thing is protection against the effects of a short circuit or overload. Time-saving fuses can not protect Solid State Relays, therefore, for proper protection, ultra-fast fuses should be used, whose Joule integral is smaller than the value of the semiconductor integral. For full protection of the relay, a varistor for overvoltage protection should be connected at the output.
Electromechanical relays
The principle of operation of electromagnetic relays is similar to the principle of operation of an electromagnetic contactor. The relay contacts have a relatively low load capacity, in the order of a few amperes. Therefore, the relay is equipped with a much smaller electromagnet than the contactor, and the contacts do not have additional arc supression devices.
The relay's dimensions are smaller than the contactor's dimensions, while the relay's durability is very high and reaches several dozen million connections. Depending on the purpose, relays have one or more pairs of contacts. They can operate under the influence of changes in current, voltage, direction of current flow, frequency, phase shift, etc. The principle of the relay operation is explained in the figure:
The flow of current through the coil winding causes the attraction of the armature. When the armature is pulled, the contacts close: (1), (2), (3) and open break contacts (4). After disconnecting the voltage and dropping the armature, the following contacts open: (1), (2), (3) and close the break contact (4). In the most common construction solutions of relays, the coil voltage is 230VAC or 24VDC, operating current of contacts - from 1 to 10A, the number of contacts - from one to four switching pairs.
Contactors
The contactor is a switch whose operating contacts are closed by means of an electromagnet and kept in this state until the coil voltage is high enough. After breaking the circuit of the electromagnet coil, the armature falls (under the influence of the spring) and the working contacts open.
The construction and operation of contactors are similar to the construction and operation of electromagnetic relays. The difference is that contactors are used to connect main circuits (e.g. motors), while electromagnetic relays have the task of connecting auxiliary circuits (e.g. control, signaling). In addition to the main contacts, the contactors may have several auxiliary contacts for signaling or blocking. The principle of the contactor operation is explained in the figure:
Under the influence of the current flowing through the contactor S coil, a force is created that attracts the armature K, which causes shorting of the main contacts Z1, Z2, Z3 and auxiliary contacts z1, z2. The contactors are mainly designed for remote connection of three-phase AC circuits in conditions specified by the use category AC3 and AC4 (connection of squirrel-cage motors). They can also be used to connect ring motors (category AC2) or heating devices (category AC1).
In addition to AC contactors, DC contactors are also available. They have an electromagnet or pneumatic drive, with both electromagnets and solenoid valves controlled by direct current. The main applications of these contactors are rail, tram and battery traction (trolleys).
The contactors offered by DACPOL are available for AC coils in the power range from 1.5 to 238kW and DC coils in the power range from 2.2 to 11kW. The instrumentation covers a wide range of auxiliary contacts and time-delay relays, interface modules and RC elements. Optionally, you can also mount thermal relays to protect electric motors.
Senden Sie eine Anfrage
Interessieren Sie sich für dieses Produkt? Benötigen Sie zusätzliche Informationen oder individuelle Preise?
Kontaktiere uns
Sie müssen eingeloggt sein
Solid State Relays
Solid State Relays (SSRs) are components used to control the current load using a semiconductor controlled by a separated electronic circuit. Galvanic separation takes place by means of an optoelectronic element such as a diode emitting infrared radiation, a photodiode, phototransistor, photothyristor or phototriac. In the rest state of the relay, when no current flows through the LED in the input circuit, the optoelectronic element remains switched off and its surrogate resistance is very large. After activating the diode, the photoelement is irradiated and it starts to conduct the switching load circuit. Such a solution allows to significantly increase the switching off frequency, eliminates the phenomenon of electric arc and enables to obtain a lifetime of 109.
Block diagram of a Solid State Relay
Depending on the type, the relay may be switched on by supplying the DC input voltage (from 3V to 32V) or alternating voltage (from 90V to 280V at 50Hz) to the input circuit. There is also the possibility of triggering the relay current. Depending on the purpose, they are built to switch on constant and alternating currents. There are also three-phase relays used, for example, for switching three-phase electric motors.
Types and application
Relays switching on at "zero" voltage – conduction occurs when the supply voltage is zero. Thanks to such a solution, it gradually builds up without causing radio interference. Used to control inductive and resistive loads (resistance heaters, bulbs). | |
Relays switching on "immediately" – the moment of switching on takes place immediately after applying the control voltage. This type of control is intended for solutions where a short response time is required. | |
Relays switching on the voltage at the "peak" - the relay is activated when the peak power supply voltage is reached. Used for strongly inductive loads (transformers). | |
Analog switching relays – controlled by an analog signal (0-10V DC or 4-20mA DC). Used for smooth control of light intensity, heating, etc. |
Parameters characterizing Solid State Relays:
Input circuit:
- control voltage range - voltage range supplied to the input, in which the relay remains switched on (eg: 3-32VDC, 9-280VAC),
- input current range - determines the maximum input current for the relay on and off state,
- switch-on and switch-off time - time elapsed since the control signal is supplied / disconnected to the full enable/disable of the relay.
Output circuit:
- load voltage range - voltage range supplied to the output terminals,
- maximum voltage - maximum permissible value of overvoltage in the power supply network that does not damage the relay,
- load current - maximum permissible value of current flowing in the output circuit,
- maximum unique overload current - maximum value of the current pulse with the duration of one half of the sinusoid,
- maximum I2 t - Joula integral value, used in the selection of fuses.
Useful parameters:
- insulation voltage – effective value of the mains voltage which can occur between the input and output terminals of the relay,
- insulation resistance – the minimum value of the resistance measured using a 500V constant current signal,
- capacity between input and output – measured between input and output terminals,
- ambient temperature range during operation.
Relay cooling
The lifetime of Solid State Relay is virtually unlimited, provided that they are properly cooled. Therefore, special attention should be paid to the selection of the heat sink, use thermal grease and ensure adequate air circulation. A good solution is to mount the relay with a heat sink on the DIN rail, leaving around free space.
Relay protection
Another important thing is protection against the effects of a short circuit or overload. Time-saving fuses can not protect Solid State Relays, therefore, for proper protection, ultra-fast fuses should be used, whose Joule integral is smaller than the value of the semiconductor integral. For full protection of the relay, a varistor for overvoltage protection should be connected at the output.
Electromechanical relays
The principle of operation of electromagnetic relays is similar to the principle of operation of an electromagnetic contactor. The relay contacts have a relatively low load capacity, in the order of a few amperes. Therefore, the relay is equipped with a much smaller electromagnet than the contactor, and the contacts do not have additional arc supression devices.
The relay's dimensions are smaller than the contactor's dimensions, while the relay's durability is very high and reaches several dozen million connections. Depending on the purpose, relays have one or more pairs of contacts. They can operate under the influence of changes in current, voltage, direction of current flow, frequency, phase shift, etc. The principle of the relay operation is explained in the figure:
The flow of current through the coil winding causes the attraction of the armature. When the armature is pulled, the contacts close: (1), (2), (3) and open break contacts (4). After disconnecting the voltage and dropping the armature, the following contacts open: (1), (2), (3) and close the break contact (4). In the most common construction solutions of relays, the coil voltage is 230VAC or 24VDC, operating current of contacts - from 1 to 10A, the number of contacts - from one to four switching pairs.
Contactors
The contactor is a switch whose operating contacts are closed by means of an electromagnet and kept in this state until the coil voltage is high enough. After breaking the circuit of the electromagnet coil, the armature falls (under the influence of the spring) and the working contacts open.
The construction and operation of contactors are similar to the construction and operation of electromagnetic relays. The difference is that contactors are used to connect main circuits (e.g. motors), while electromagnetic relays have the task of connecting auxiliary circuits (e.g. control, signaling). In addition to the main contacts, the contactors may have several auxiliary contacts for signaling or blocking. The principle of the contactor operation is explained in the figure:
Under the influence of the current flowing through the contactor S coil, a force is created that attracts the armature K, which causes shorting of the main contacts Z1, Z2, Z3 and auxiliary contacts z1, z2. The contactors are mainly designed for remote connection of three-phase AC circuits in conditions specified by the use category AC3 and AC4 (connection of squirrel-cage motors). They can also be used to connect ring motors (category AC2) or heating devices (category AC1).
In addition to AC contactors, DC contactors are also available. They have an electromagnet or pneumatic drive, with both electromagnets and solenoid valves controlled by direct current. The main applications of these contactors are rail, tram and battery traction (trolleys).
The contactors offered by DACPOL are available for AC coils in the power range from 1.5 to 238kW and DC coils in the power range from 2.2 to 11kW. The instrumentation covers a wide range of auxiliary contacts and time-delay relays, interface modules and RC elements. Optionally, you can also mount thermal relays to protect electric motors.
