PQAE series DC / DC converters
  • PQAE series DC / DC converters

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: Cosel

PQAE series DC / DC converters

Key product features

  • 1/4 Brick Package Size
  • Ultra Wide 12:1 Input
  • Railway Approved
  • Low Standby Power
  • Up to 160V Input and Up to 53V Output
  • 39W-150W Output Power

Industries

  • Communication
  • Industrial
  • Mil Def Compliant
  • Railway Approved
  • Railway Compliant
  • Transportation

Technical features

  • < 1U High
  • Remote On/Off
PQAE Models Input Voltage Output Type Output Voltages Output Power
PQAE100-110SW DC40 - 160V Single 3.3V, 5V, 12V, 15V, 24V, 30V, 48V 100W
PQAE100-24SW DC8.5 - 36V Single 3.3V, 5V, 12V, 15V, 24V, 30V, 48V 100W
PQAE100-36SU DC9 - 75V Single 5V, 12V, 15V, 24V, 28V, 48V, 53V 100 - 100.8W
PQAE100-48SW DC16.5 - 75V Single 3.3V, 5V, 12V, 15V, 24V, 30V, 48V 100W
PQAE100-72SU DC14 - 160V Single 5V, 12V, 15V, 24V, 28V, 48V, 53V 100 - 100.8W
PQAE150-110SW DC40 - 160V Single 3.3V, 5V, 12V, 15V, 24V, 30V, 48V 150W
PQAE150-24SW DC8.5 - 36V Single 3.3V, 5V, 12V, 15V, 24V, 30V, 48V 150W
PQAE150-48SW DC16.5 - 75V Single 3.3V, 5V, 12V, 15V, 24V, 30V, 48V 150W
PQAE40-36SU DC9 - 75V Single 5V, 12V, 15V, 24V, 28V, 48V, 53V 39.75 - 40.08W
PQAE40-72SU DC14 - 160V Single 5V, 12V, 15V, 24V, 28V, 48V, 53V 39.75 - 40.08W
PQAE60-36SU DC9 - 75V Single 5V, 12V, 15V, 24V, 28V, 48V, 53V 60 - 60.42W
PQAE60-72SU DC14 - 160V Single 5V, 12V, 15V, 24V, 28V, 48V, 53V 60 - 60.42W
