Manufacturer: ELECTRONICON Kondensatoren

E80.N18-294NL00 DC capacitors with ultra-free inductance

  • E80.N18-294NL0
  • CN (µF) 290
  • UN (V DC) 1300
  • UBG (V AC) 4320
  • Ur (V) 300
  • US (V) 1950
  • UBB (V DC) 1950
  • Rth (K/W) 44623
  • D1(mm) 85
  • L1 (mm) 180
  • Î (kA) 44622
  • IS (kA) 44810
  • EN (Ws) 245
  • Le (nH) 15
  • pcs / Box 5/FB12
  • Imax (A) 80
