Manufacturer: ELECTRONICON Kondensatoren

E62.L10-403G10 AC capacitors optimized for high effective currents

  • E62.L10-403G10
  • CN (µF) 40
  • UN (V DC) 1260
  • UBG (V AC) 3000
  • US (V) 1900
  • UBB (V DC) 1890
  • Rth (K/W) 44715
  • D1(mm) 65
  • L1 (mm) 109
  • Î (kA) 0.7
  • IS (kA) 2
  • Le (nH) 120
  • pcs / Box 10/FB1
  • Design G1
  • Urms (V) 530
  • Imax (A) 30
