VersionPodwójny x pełny rozmiar (H x W)
na 2 x zasilacz wtykowy z wtyczką Positronic 47 Pin
Height (U)3,5 U
Width (HP)16 HP
Packed after1 część
These are used as face plates for AMC cards and ATCA carriers, or as filler panels in MicroTCA systems.
Installation in μTCA systems or AMC carriers
Conforms to AMC.0 R2.0
Height: Single & Double
Widths: Compact, Mid-Size, Full-Size
Simple handling when locking and unlocking (no screws)
Hot swap-compatible injector/extractor handles
Customer-specific face plates available with a short lead time
Upgradable with filler sheets and air baffle plates
Double to Single conversion module (accessory)
Material: Face plate made from aluminum, (stainless steel available on request) Holder for light pipe and PCB, die-cast Zn Light pipe, polycarbonate Handle, die-cast Zn, spray-finished EMC seal, foam with metal fabric (UL 94 V0)
Supply includes: 1 U-channel face plate, 1 holder to accommodate a light pipe and PCB, 1 handle for microswitch, 1 light pipe (for 2 LEDs), 1 EMC gasket, left side and bottom.
