Amplifiers and transmitters

TRANSMITTERS BANDWIDTH FM: 87,5-108MHZ


Type Class Amplification[dB] POUT
[W]
MDL30 AB 17 30
MDF30 AB 30 30
FM300-108SD B 17 300
FM300-108M B 17 300
FM500-108-S B 18 500
FM500-108C B 18 50


AMPLIFIERS BANDWIDTH: 1-30 MHZ


Type Class Amplification[dB] Pout[W]
HF06-ISM AB 12 6
HF10-0130 A 22 10
HF300-0130M AB 22 300


AMPLIFIERS BANDWIDTH VHF: 170-235 MHZ


Type Class Amplification[dB] Pout[W]
LDV05M AB 21 5
THV15-V2 A 31.0 15
THV60 A 14.0 60
LDV75M AB 22 75
THV410C AB 14.5 300
THV400 AB 15 300
THV450C AB 14.5 450
THV500 AB 14.5 250

AMPLIFIERS BANDWIDTH UHF: 470-862 MHZ

Type Class Amplification [dB] Pout
[W]
LDU25 AB 14 25
THU35 A 9,5 35
THU2600A A 10,5 25
THU2640 A 11,5 60
THU2602A A 8,5 40
LDU45 AB 13 45
LDU60 AB 16 60
THU2604-S AB 8 175
THU2604 AB 8.0 175
LDU200 AB 13,5 200
LDU310C AB 14 310
LDU400C/TR AB 15 400

Caution
Please contact us if you are interested in other options
