Manufacturer: HEITEC AG

3688130 ATX power supply 1 U

  • 3688130
  • Version ATX
  • Width (HP) 21 HP
  • to PCB depth 160 mm
  • Top- / Bottom covers wentylowany
  • Packed after 1 część
For ATX
  • 2 built-in fans
  • Short circuit-protected
  • On/off switch
  • PFC active
  • W x H x D = 85 x 40 x 230 mm
Supply includes: Connection cable.

Technical specifications:
  • 250 W max./
  • 90 – 264 V AC
  • 47 – 63 Hz
  • 3.3 V/16.0 A
  • 5.0 V/18.0 A
  • –5.0 V/0.3 A
  • 12.0 V/18 A
  • –12.0 V/0,8 A
  • +5 VS B/2,5 A
  • +3.3 V plus 5 V total
  • max. 120 W
