4418 ml Axial fan
  • 4418 ml Axial fan
  • 4418 ml Axial fan
  • 4418 ml Axial fan

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: Ebmpapst

4418 ml Axial fan

  • 4418 ML
  • Cable z wyprowadzeniami AWG 24, TR 64
  • Air flow direction Wydech nad rozpórkami
  • Dimensions 119 x 119 x 38 mm
  • Housing material Tworzywo PBT wzmocnione włóknem szklanym
  • Nominal voltage 48
  • Speed 3000
  • Power input 3.2
  • Min. ambient temperature -20
  • Max. ambient temperature 75
  • Air flow 168
  • Sound pressure level 40
  • Voltage range 36 .. 60
  • Bearing Łożysko kulkowe
  • Direction of rotation Zgodnie z ruchem wskazówek zegara, patrząc w kierunku wirnika
  • Rotor material Tworzywo PA wzmocnione włóknem szklanym
  • Lifetime L10 at 40 ° C 67500 h
  • L10 lifetime at maximum temperature 27500 h
  • Sound power level 5.1
  • Weight 0.270 kg
