DC/DC converters in EUROKASETA casing
  • DC/DC converters in EUROKASETA casing

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: Bel Power Solutions

DC/DC converters in EUROKASETA casing

technical data:
Output voltage        5…48V ( 1- 3 outputs)
Operation temperature        –40…+71°C natural cooling
high EMC resistance
Control of output voltage
Galvanic insulation  I/O, O/O
Universal AC input
High resistance for shocks
Thermal, over voltage and current protection
6 input voltage ranges A = 8 d- 35VDC, B = 14 - 70VDC,
C = 28 - 140VDC, D = 44 - 220VDC, E = 67 - 385VDC, F = 20 - 100VDC,


Power Series Dimensions
50W M series 3U x 8HP (39x168x111mm)
100W S series 3U x 12HP(60x168x111mm)
150W K series 3U x 16HP(80x168x111mm)


Seria RCM 150/300 W do zastosowań trakcyjnych

Seria RCM 150/300 W do zastosowań trakcyjnych

Model Vi min 1
[V]		 Napięcie wejściowe
Vi cont
[V]		 Vi max1 [V] Wyjście Moc
Po nom
[W]		 Wydajność Opcje
Vo nom
[V]		 Io nom
[A]		 ηmin2
[%]		 ηtyp
[%]

24RCM150-12

 14.4 16.8 (24) 45 50.4 12 12.5 150 88   D, M, Q, F

24RCM150-24

 24 6.25 150 89

110RCM150-12

 43.2 50.4 (110) 137.5 154 12 12.5 150 90 93 D, M, Q, F

110RCM150-24

 24 6.25 150 91

24RCM300-12

 14.4 16.8 (24) 45 50.4 12 25 300 89   D, M, Q, F

24RCM30024

 24 12.5 300 90

110RCM300-12

 43.2 50.4 (110) 137.5 154 12 25 300 91   D, M, Q, F

110RCM300-24

 24 12.5 300 92

1 Short time; see table 2 for details
2 Efficiency at TA= 25 °C, Vi nom, lo nom,Vo nom, no option fitted
D - Out OK, output voltage adjust, shutdown 1, M - Interruption time, Q - ORing FET, F - Fuse

Wymiar [mm]

RCM150

RCM300

Seria RCM 150/300 W do zastosowań trakcyjnych

Seria RCM 500/1000W do zastosowań trakcyjnych

Seria RCM 500/1000W do zastosowań trakcyjnych

Model Vi min 1
[V]		 Napięcie wejściowe
Vi cont
[V]		 Vi max1 [V] Wyjście Moc
Po nom
[W]		 Wydajność Opcje
Vo nom
[V]		 Io nom
[A]		 ηmin2
[%]		 ηtyp
[%]

110RCM500-24

 66 77 (110) 137.5 154 24 21 504 96   D, M, Q, F

110RCM1000-24

 24 42 1008 96

1 Short time; see table 2 for details
2 Efficiency at TA= 25 °C, Vi nom, lo nom,Vo nom, no option fitted
D - Out OK, output voltage adjust, shutdown 1, M - Interruption time, Q - ORing FET, F - Fuse

RCM500

RCM1000

Przetwornice DC/DC w obudowie eurokaseta - RCM500, RCM1000
