Fast diodes

Type
IF(AV)/Tc
[A°c]
URRM
[V]
UFM
[V]
trr
[µs]
Casing type
60HFU-60OM
60
600
1,5
60
DO-203AB(DO-5)
70HFL(R)100S05M
70
1000
1,85
500
70HFL(R)60S02M
70
600
1,85
200
85HFL(R)100S05M
85
1000
1,75
500
85HFL(R)60S02M
85
600
1,75
200

Diode type
IF(AV)/Tc
[A°c]
URRM
[V]
IFSM
[A]
I2t
[A2s]
trr
[µs]
Rthjc
[°c/w]
Rthcs
[°c/w]
Clamping force
[Nm(kN)]
Casing Drawing
SD103N(R)..S..
110/85
400-2500
3570
64000
1-2
0,16
0,1
15,5
DO-205AC(DO-30)
drw.1
SD153N(R)..S..
150/85
400-1600
4280
92000
1-1,5
0,16
0,1
15,5
SD203N(R)..S..
200/85
400-2500
4990
125000
1-2
0,115
0,08
24,5
DO-205AB(DO-9)
drw3
SD253N(R)..S..
250/85
400-1600
5350
143000
1,5-2
0,115
0,08
24,5
SD233N(R)..S..
235/60
3000-4500
5500
151000
4,5
0,1
0,04
50
B-8
drw.2
SD453N(R)..S..
400/70
1200-2500
9300
432000
2
0,1
0,04
50

450/70

9600
460000
3

SD303C..S..C
350/55
400-2500
5770
166000
1-2
0,08

4,9
DO-200AA(A-Puk)
drw.4
SD403C..S..C
430/55
400-1600
6180
191000
1-1,5
0,08

4,9
SD603C..S..C
600/55
400-2200
8320
346000
1-2
0,038

9,8
B-43(E-Puk)
drw.5
SD823C..S..C
810/55
1200-2500
9300
432000
2
0,038

9,8

910/55
1200-2500
9600
460000
3
0,038

9,8
SD803C..S..C
845/55
400-1600
11295
640000
1-1,5
0,038

9,8
SD263C..S50L
375/55
3000-4500
5500
151000
4,5
0,05

9,8
DO-200AB(B-Puk)
drw.6
SD553C..S50L
560/55
3000-4500
12000
721000
6
0,031

14,7
SD703C..S..L
700/55
1200-2500
9300
432000
2
0,046

9,8

790/55
1200-2500
9600
460000
3
0,046

9,8
SD1053C..S..L
1050/55
1800-2500
15000
1125000
2
0,031

14,7

920/55
1800-3000
13000
845000
3
0,031

14,7
SD853C..S50K
990/55
3000-4500
19000
1810000
5
0,02

22,25
DO-200AC(K-Puk)
drw.7
SD1053C..S..K
1050/55
1800-2500
15000
1125000
2
0,02

22,25

920/55
1800-3000
13000
845000
3
0,02

22,25
SD1553C..S.K
1825/55
1800-2200
21030
2211000
2
0,02

22,25

1650/55
1800-3000
18500
171000
3
0,02

22,5
SD2053..S.R
2000/55
3200-4500
25600
3276000
5
0,01

43
B-44(R-Puk)
drw.8
SD3535..S.R
3500/55
1600-2500
40200
8080000
2
0,01

43
