3688773 IVS handle, with 1/2 hp offset, bottom
  • 3688773 IVS handle, with 1/2 hp offset, bottom
  • 3688773 IVS handle, with 1/2 hp offset, bottom

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: HEITEC AG

3688773 IVS handle, with 1/2 hp offset, bottom

  • 3688773
  • Version Montaż na dole, z przesunięciem 1/2 HP
  • Width (HP) 42 HP
  • to PCB depth 160 mm
  • Top- / Bottom covers wentylowany (szczeliny wentylacyjne)
  • Packed after 1 część
With push-button
For inserting and removing connectors with a large number of pins. A metal insert ensures reliable functioning, even at forces of up to 815 N.
  • Insertion/removal function
  • Push-button for locking and unlocking the board type plug-in unit (cannot be extracted in the locked position)
  • Optionally with ½ HP offset PCB attachment, e. g. for component mounting on both sides
  • Optional integral micro-switch for “live insertion” applications
  • ES D pin to dissipate static charges before contacting the connectors and for precise positioning of the board type plug-in unit
  • Keyable
  • Integral PCB attachment
  • Bayable
Material: Plastic/metal

Supply includes: Assembly parts.

Note:
  • Insertion only when used with front horizontal rails, with 10 mm extension (B, B1, B2)
  • With 3 U front panels, only one extractor handle is required.
