Manufacturer: FUTABA

FUTABA O.S. MAX GF40 ENGINE - F-6040 MUFFLER, GASOLINE

The FUTABA GF40 is a 40cc four-stroke gasoline engine designed for scale and aerobatic aircraft. It is equipped with a dual-needle Walbro WT1070 carburetor with a choke. Known for its fuel cost efficiency, the engine operates on a mixture of motor oil and standard gasoline. The basic kit also includes an IG-04 electronic ignition system and an F-6040 expansion chamber muffler.

Displacement [cm³] 39.96
Number of cylinders 1
Cylinder diameter [mm] 40
Piston stroke [mm] 31.8
RPM [rev/min] 1800 - 9000
Engine power (at 8600 RPM) [kW] 2.79
Power (at 8600 RPM) [HP] 3.8
Weight (engine) [g] 1170
Weight (muffler) [g] 113
Weight (ignition) [g] 95
Recommended spark plug CM-6
Recommended tank capacity [ml] 300 - 400
Drive screw nut thread UNF 5/16-24
