3687669 Heipac Vario Compact 3U, 21 Te, 225 mm for mounting panel
  • 3687669 Heipac Vario Compact 3U, 21 Te, 225 mm for mounting panel
  • 3687669 Heipac Vario Compact 3U, 21 Te, 225 mm for mounting panel

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: HEITEC AG

3687669 Heipac Vario Compact 3U, 21 Te, 225 mm for mounting panel

  • 3687669
  • Series Heipac Vario Compact
  • Colour RAL 7035
  • Version Obudowa podstawowa
  • Height (U) 6 U
  • Width (HP) 84 HP
  • Side panel depth 370,4 mm
  • Packed after 1 Zestaw
  • EMC nie
For mounting plates or top-hat rails
  • Compact dimensions in 21 HP and 42 HP
  • Adapter for rail mounting
  • Flange for wallmounting
Material/surface finish:
  • Side panels: 2.5 mm aluminum, clear-chromated
  • Flanges and horizontal rails: Extruded aluminum section, clear-chromated
Supply includes:
  • Side panels
  • rear trims
  • flanges for mounting plates or top-hat rail adaptors
  • EMC front/rear panels
  • EMC gaskets
  • covers
  • horizontal rails
  • threaded inserts
  • insulating strips.
Tests:
Shock and vibration tested to:
  • IEC 600-68-2-6 test Fc
  • IEC 600-68-2-27 test Ea
Standards:
HeiPac subracks are based on the system dimensions of IEC 60 297-3.
Less
Read more

Send an inquiry

Are you interested in this product? Do you need additional information or individual pricing?

Contact us
ASK FOR THE PRODUCT close
Thank you for sending your message. We will respond as soon as possible.
ASK FOR THE PRODUCT close
Browse
send an inquiry

Add to Wishlist

You must be logged in

  • Series Heipac Vario Compact
  • Colour RAL 7035
  • Version Obudowa podstawowa
  • Height (U) 6 U
  • Width (HP) 84 HP
  • Side panel depth 370,4 mm
  • Packed after 1 Zestaw
  • EMC nie
For mounting plates or top-hat rails
  • Compact dimensions in 21 HP and 42 HP
  • Adapter for rail mounting
  • Flange for wallmounting
Material/surface finish:
  • Side panels: 2.5 mm aluminum, clear-chromated
  • Flanges and horizontal rails: Extruded aluminum section, clear-chromated
Supply includes:
  • Side panels
  • rear trims
  • flanges for mounting plates or top-hat rail adaptors
  • EMC front/rear panels
  • EMC gaskets
  • covers
  • horizontal rails
  • threaded inserts
  • insulating strips.
Tests:
Shock and vibration tested to:
  • IEC 600-68-2-6 test Fc
  • IEC 600-68-2-27 test Ea
Standards:
HeiPac subracks are based on the system dimensions of IEC 60 297-3.
