9921862 Heipac Vario Heavy 6U, 245 mm, without hole
  • 9921862 Heipac Vario Heavy 6U, 245 mm, without hole
  • 9921862 Heipac Vario Heavy 6U, 245 mm, without hole

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: HEITEC AG

9921862 Heipac Vario Heavy 6U, 245 mm, without hole

  • 9921862
  • Series Heipac Vario Heavy
  • Version Panel tylny na 1 złącze
  • Height (U) 3 U
  • Width (HP) 14 HP
  • Packed after 1 część
Subrack system for mobile applications and rough ambient conditions.
! Available as of April 2017 !
  • Reinforced flange ensures high resistance to shock and vibrations
  • Horizontal rails with double screw fastening provide high mechanical strength
  • Shock/vibration testing in accordance with : EN 50155 (EN 61373, category 1, class B)
  • Shock/vibration testing in accordance with : IEC 61587-1 (DL2V/DL2S)
  • Extensive accessories from HeiPac Vario family allow for a wide range of expansion options
  • EMC can be retrofitted

Material/surface finish
  • Side panels: 2.5 mm Aluminium, clear-chromated
  • Horizontal rails: Extruded aluminium section, clear-chromated
  • Flanges: Extruded aluminium section, clear-chromated

Supply includes
  • Side panels, flanges, horizontal rails, threaded inserts, assembly screws

Tests
  • Shock and vibration tested in accordance with: DIN EN 61587-2 EN 50 155

Standards
  • HeiPac subracks are based on the system dimensions of IEC 60 297-3
