Manufacturer: HEITEC AG

9908721 Horizontal front, with double screwing (V2), unprinted

  • 9908721
  • Version niezadrukowane
  • Height (mm) 128,4 mm
  • Width (mm) 100 mm
  • Number of slots 5 Slot
  • Packed after 1 część
To accommodate guide rails and for the attachment of front panels. The double screw fastening ensures a high level of stability even under extreme loads.
  • Load test to DIN EN/IEC 61 587-1, requirement level SL1
  • Shock and vibration tests undertaken as per IEC 61 373 (DIN EN 50 155), Category 1, Class B
  • Front projection 2.5 mm corresponding to IEC 60 297-3-101
  • HP pitch pattern of holes for the precise installation of guide rails
  • M4 thread on end face
  • Straight-through core hole
