Controller-Module: Monitoring of system voltage, PSU-status,HeiCool alarm and data transfer of the temperature-and/or fan module via RS232- (to PC) orRS422- interface (to CMC-TC).LED Display-Module:
+ 3.3 V
+ 5.0 V
+ 12 V
- 12 V
2 x alarm (fan, temperature)
Display of system voltage as to critical values
Red: voltage deficiency
Yellow (1 flash): below limit
Yellow (2 flashes): over limit
Green: voltage ok
Supply includes: Unit consisting of: controller-module, LED-module, front panel 6 U, 4 HP
