FFMYD-V0 protective pezel
  • FFMYD-V0 protective pezel

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: Fränkische

FFMYD-V0 protective pezel

Technical data
Peszel ochronny FFMYD-V0 dane techniczne

Preferences

Material
PA 6 - V0
Max. operation temperature
3000 h 120 OC

500 h 150 OC
Min, operation temperature
-40OC
Flammability class
UL94 V0
Non halogen
yes
Material declaration needed
no
Other informations

Chemical resistance:

Fuels, Mineral oils, grease, dis solvents.
- cut products
417-xxx-10
- other lenghts:
request
- special coloures
request

Dimensions

Peszel ochronny FFMYD-V0 wymiary

Product number
black colour
Cut product number grey colour Nominal diamtr
NW
Ø - I
[mm]
Ø - A
[mm]

417-003-00

417-003-10

3 3,0 5,1

417-004-00

417-004-10

4,5 4,5 7,1

417-005-00

417-005-10

5 5,0 7,1

417-006-00

417-006-10

6 6,1 8,7

417-007-00

417-007-10

7,5 6,6 10,0

417-008-00

417-008-10

8,5 8,4 11,5

417-010-00

417-010-10

10 9,8 12,8

417-011-00

417-011-10

11 10,5 13,6

417-012-00

417-012-10

12 12,3 15,7

417-013-00

417-013-10

13 12,7 16,0

417-014-00

417-014-10

14 14,2 18,5

417-016-00

417-016-10

16 14,9 18,9

417-017-00

417-017-10

17 16,6 21,1

417-019-00

417-019-10

19 19,2 24,2

417-022-00

417-022-10

22 21,2 25,5

417-023-00

417-023-10

23 23,1 28,4

417-026-00

417-026-10

26 25,7 31,2

417-029-00

417-029-10

29 28,9 34,5

417-033-00

417-033-10

33 32,8 38,3

417-037-00

417-037-10

37 34,0 42,2

417-050-00

417-050-10

50 45,6 53,8

417-065-00

417-065-10

65 62,7 73,5

417-075-00

417-075-10

75 76,7 85,2

417-100-00

417-100-10

100 101,0 110,0
