Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: M-SYSTEM

B3FR - two-wire temperature converter with RTD input

  • B3FR

B3FR is a two-wire temperature converter with RTD input.


Features

  • Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without interfering with the wiring
  • DC power supply
  • Provides a standard analog signal
  • Configurable range of inputs
  • DIN rail mounting
  • 2000V AC insulation

Types of inputs: RTD - Pt 100 (JIS'97, IEC), Ni 100, Cu 10 @ 25 ℃
Types of outputs: current 4… 20mA
Possibility to make the range of inputs / outputs on special order.


Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric Strength For DC power: 2000V AC
Range selection Configurable input range
Double Output None
Power DC
Working Temperature - 40 to + 85 ° C
Montage On a DIN rail
Dimensions 18x106x110.5mm
