Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: M-SYSTEM

B5RS - two-wire signal converter with temperature input

  • B5RS

B5RS is a two-wire converter with thermocouple temperature input - loop-powered.


Features

  • Provides an isolated DC output signal
  • Loop powered
  • Linearization
  • 4… 20mA output signal
  • DIN rail mounting
  • 2000V AC insulation
  • Power LED

RTD - JPt 100 (JIS'89), Pt 100 (JIS'89), Pt 100 (JIS'97, IEC), Pt 50Ω (JIS'81), Ni 508.4Ω, Pt 1000, Ni 100, Cu 10 @ 25 ℃
Types of outputs: current 4… 20mA
Possibility to make the range of inputs / outputs on special order.


Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric Strength For DC power: 2000V AC
Range selection Input - 100Ω - 10kΩ, output 4… 20mA
Double Output None
Power DC
Working Temperature - 40 to + 80 ° C
Montage On a DIN rail
Dimensions 25x41x97mm
