W2DYH2 - Current loop power supply for HART signals with two outputs

  • W2DYH2

W2DYH2 is a current loop power supply - dual output.


Features

  • Power supply for HART signals
  • Open circuit detection
  • It powers the 4 ... 20mA DC loop
  • Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without interfering with the wiring.
  • Electrically isolates the output signal from power inputs
  • Provides galvanic isolation
  • Short-circuit protection
  • Output power - 24 V DC
  • AC / DC power

Input: 4… 20mA
Output: 4… 20mA


Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric Strength na DC: 2000V AC
AC: 1500V AC
Range Selection None
Double Exit < / th> Yes
Power AC / DC
Operating Temperature -5 to + 55 ° C
Mounting On a DIN rail
Dimensions 29.5x76x124mm
