M2DU - current loop power supply
  • M2DU - current loop power supply

Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: M-SYSTEM

M2DU - current loop power supply

  • M2DU

M2DU is a 10 ... 50mA DC loop power supply.


Features

  • It supplies the 10 ... 50mA DC current loop
  • Mounting socket for of each model - enables easy assembly / disassembly and quick conversion of converters without interfering with the wiring.
  • Short-circuit protection
  • Power on the output - 24 V DC
  • AC power / DC

Input: 10… 50mA DC
Output: 1… 5V DC
Power supply: AC / DC


< / tr>
Less
Read more

Send an inquiry

Are you interested in this product? Do you need additional information or individual pricing?

Contact us
ASK FOR THE PRODUCT close
Thank you for sending your message. We will respond as soon as possible.
ASK FOR THE PRODUCT close
Browse
send an inquiry

Add to Wishlist

You must be logged in

M2DU is a 10 ... 50mA DC loop power supply.


Features

  • It supplies the 10 ... 50mA DC current loop
  • Mounting socket for of each model - enables easy assembly / disassembly and quick conversion of converters without interfering with the wiring.
  • Short-circuit protection
  • Power on the output - 24 V DC
  • AC power / DC

Input: 10… 50mA DC
Output: 1… 5V DC
Power supply: AC / DC


Wire connection Terminals M3 screw screws
Separation Input / Output / Power
Dielectric strength DC power: 2000V AC
AC power : 1500V AC
Select r ranges None
Double exit None
Power AC / DC
Operating Temperature - 5 to +55 ° C
Mounting DIN rail
Dimensions 23x76x124mm
