Photos are for informational purposes only. View product specification

please use latin characters

Manufacturer: M-SYSTEM

M2LCS - Tensometric transducer

  • M2LCS

M2LCS is a strain gauge transducer.


Features

  • Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without interfering with the wiring < / li>
  • Electrically isolates the output from the power input
  • Provides the required excitation voltage
  • Adjustable excitation from 2 to 10V
  • Provides a DC output signal compatible with bridge type, strain gauge used in strain gauges, pressure transmitters
  • Provides galvanic isolation
  • AC / DC power

Strain gauge input: 1mV / V, 1.25mV / V, 1.5mV / V, 2mV / V, 3mV / V, 4mV / V, 5mV / V, 10mV / V, 20mV / V
Output: current or voltage with different ranges


< td style = "padding-left: 20px"> None < / tr> < th style = "padding-left: 20px"> Dimensions
Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric strength DC: 2000V AC
AC: 1500V AC
Ranges selection
Double Exit None
Power AC / DC
Operating Temperature - 5 to + 55 ° C
Mounting DIN rail
29.5x76x124mm
