Regulador de temperatura para carril DIN ET1122 (maestro) y ET1112 (esclavo)
  • Regulador de temperatura para carril DIN ET1122 (maestro) y ET1112 (esclavo)

Las fotos son solo para fines informativos. Ver especificaciones de producto

please use latin characters

Fabricante: Sisel

Regulador de temperatura para carril DIN ET1122 (maestro) y ET1112 (esclavo)

Temperature controller for DIN bus DIN ET1122 (master) and ET1112 (slave)


Controller ET1122 is fixed on the DIN bus. It is one channel "master" element. By adding another ET1112 slave modules it is possible to complete multi channel regulator.


Features of ET1122 and ET1112

  • DIN assembly;
  • Universal input for Pt100 sensor, thermocouples and analog sensors;
  • Relay outputs and SSR;
  • possibility to connect further segments with further control channels;
  • Modbus RS485 communication;
  • Execution according to European standards.

Technical data

ET1122 (master)
 ET1112 (slave)
Dimensions [mm] 25,5 x 91 x 65 Dimensions [mm] 25,5 x 91 x 65
Mounting DIN rail Mounting DIN rail
Weight 200g (incl. packaging) Weight 200g (incl. packaging)
Power supply
 24VDC±10%, 50/60Hz Power supply 24VDC±10%, 50/60Hz (after connection with ET1122)
Input type
 Pt100, 0..20mA, 4..20mA,
Thermocouple (J, K, T, S, R)		 Input type Pt100, 0..20mA, 4..20mA,
Thermocouple (J, K, T, S, R)
Operating temperature
 0..50 °C Operating temperature 0..50 °C
Regulation type
 on-off, P, PI, PID Regulation type on-off, P, PI, PID
Output type
 2x relay, analog 0/4..20mA, SSR Output type 2x relay, analog 0/4..20mA, SSR
Communications Modbus RS485 Communications Modbus RS485
