- Temperature limiter and self control (PTC).
- Wide range of power supply
- Dynamic heating without electromagnetic noise.
- Energy-saving and easy to maintain.
- Small dimensions, compact.
Technical data
• Heating element: | Thermistor (PTC) - self controlled with temperature limiter. |
• Heating body | Anodized aluminium profile. |
• Mounting | Mounting clamp for DIN bus 35 mm, EN 50022 |
• Assemble: | Vertical |
• Operation temperature | - 45°C - +70°C |
• IP | IP 54 /II |
• Equipment | 2 screws number. 09024.0-00 |
![]() |
![]() |
Article number | Nominal voltage | Heating power | Max turn on current | Length (L) |
Weight | Terminals | Aprobacje | |
---|---|---|---|---|---|---|---|---|
04700.0-00 |
AC/DC 110-250 V2) | 10W | 1,0A | 50 mm | 0,10 kg | Silicone cable 3x0,5 mm² x 300 mm | VDE | EAC |
04701.0-00 |
AC/DC 110-250 V2) | 20 W | 2,5 A | 60 mm | 0,20 kg | Silicone cable 3x0,5 m²m x 300 mm | VDE | EAC |
04702.0-00 |
AC/DC 110-250 V2) | 30 W | 3,0 A | 70 mm | 0,20 kg | Silicone cable 3x0,5 mm² x 300 mm | VDE | EAC |
04700.9-00 |
AC/DC 110-120 V | 10W | 1,0A | 50 mm | 0,10 kg | Silicone cable 3x0,5 mm² x 300 mm | ULFileNo. E150057 | EAC |
04701.9-00 |
AC/DC 110-120 V | 20 W | 1,5A | 70 mm | 0,20 kg | Silicone cable 3x0,5 mm² x 300 mm | ULFileNo. E150057 | EAC |
04702.9-00 |
AC/DC 110-120 V | 30 W | 1,5A | 100 mm | 0,20 kg | Silicone cable 3x0,5 mm² x 300 mm | ULFileNo. E150057 | EAC |
