Technical data
Marking (94/9/EC): | ![]() ![]() |
---|---|
Enclosure type: | EEx de IIC T6 I Ex tD A21 IP66 T67 °C |
Atest | PTB 98 ATEX 3121 |
Enclosure | polyamide |
Protection class EN 60529 | IP 66 |
Connection parameters: | voltage rating : 250 V~ current rating 16 A |
Cable glands: | 1 x EEx e II M 25 x 1,5 dla kabli o średnicy 0 od 8 - 17 mm |
Terminal connectors: | operating terminals 2 x 2,5 mm2 PE terminals 4 x 2,5 mm2 |
Weight: | 0,32 kg |
Order information
Type | Contacts | Cable glands | Order No. |
---|---|---|---|
2-way connection switch | ![]() |
1 x M25 2 x M25 2 x M20* |
GHG 273 2000 R0017 GHG 273 2000 R0018 GHG 273 2000 R0003 |
Switch (stair) | ![]() |
1 x M25 2 x M20* 2 x M25 |
GHG 273 6000 R0011 GHG 273 6000 R0003 GHG 273 6000 R0014 |
Ring button | ![]() |
1 x M25 2 x M25 |
GHG 273 4000 R0004 GHG 273 4000 R0007 |
