Gamintojas: M-SYSTEM

W5PA - signalo keitiklis su dažnio įvedimu su dviguba išėjimu

  • W5PA

W5PA is a frequency input converter with two outputs.


Features

  • Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without interfering with the wiring
  • DC / AC power
  • Double exit
  • Converts the output from the pulse converter into a standard analog signal
  • DIN rail mounting
  • 2000V AC insulation

Input types: dry contact, voltage or current pulse
Types of outputs: current or voltage with different ranges
Possibility to make the range of inputs / outputs on special order.


Wire connection M3 screw terminals
Separation Input / Output / Power
Dielectric Strength For DC power: 2000V AC
When powered by AC: 1500V AC
Range selection Programmable via PC and buttons on the front of the case
Double Output Yes
Power AC / DC
Working Temperature - 5 to + 55 ° C
Montage On a DIN rail
Dimensions 45x41x97mm
