Nuotraukos yra skirtos tik informaciniams tikslams. Peržiūrėkite produkto specifikaciją

please use latin characters

Gamintojas: M-SYSTEM

M2RT - temperatūros konverteris su MTTP įvestuvu

  • M2RT

M2RT is a temperature converter with RTD input.


Features

  • Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without the need for intervention cabling
  • For PV systems
  • AC / DC power
  • LED power indicator
  • DIN rail mounting
  • 2000V AC isolation
  • Quick Response Type Available

Input Types: RTD - JPt 100 (JIS'89), Pt 100 (JIS'89), Pt 100 (JIS'97, IEC), Pt 50Ω (JIS'81), Ni 508.4Ω, Pt 1000, Ni 100, Cu 10 @ 25 ° C
Types of outputs: current or voltage with different ranges
Possibility execution of the range of inputs / outputs on a special order.


< th style = "padding-left: 20px"> Mounting
Wire connection M3 screw terminals
Separation < / th> We jście / Output / Power
Dielectric strength DC power: 2000V AC
When powered by AC: 1500V AC
Ranges selection To be set when ordering
Double exit None
Power AC / DC
Operating temperature - 20 to + 80 ° C
DIN Rail
Dimensions 23x76x124mm
mažiau
