![Separator 2-canal MTL4513-MTL5513 Separator 2-canal MTL4513-MTL5513](https://www.dacpol.eu/7427-large_default/separator-2-canal-mtl4513-mtl5513.jpg)
![Separator 2-canal MTL4513-MTL5513 Separator 2-canal MTL4513-MTL5513](https://www.dacpol.eu/7427-large_default/separator-2-canal-mtl4513-mtl5513.jpg)
trebuie să fii logat
Fotografiile au doar scop informativ. Vizualizați specificațiile produsului
please use latin characters
The MTLx513 enables two solid-state outputs in the safe area to be controlled by two switches or proximity detectors located in the hazardous area. The Ch1/Ch2 output transistors share a common terminal and can switch +ve or -ve polarity signals. Independent output phase reversal and line fault detection are enabled via switches for each output. LFD indication is provided on the top of the module.Specification
(*) Resistors must be fitted when using the LFD facility with a contact input: 500 Ohm to 1kΩ in series with switch 20 kOhm to 25kΩ in parallel with switch (**) Note: reactive loads must be adequately suppressed. |
Relay characteristics
SIL capable
|
