RTD - JPt 100 (JIS'89), Pt 100 (JIS'89), Pt 100 (JIS'97, IEC), Pt 50Ω (JIS'81), Ni 508.4Ω, Pt 1000, Ni 100, Cu 10 @ 25 ℃
Types of outputs: current 4… 20mA
Possibility to make the range of inputs / outputs on special order.
Wire connection | M3 screw terminals |
---|---|
Separation | Input / Output / Power |
Dielectric Strength | For DC power: 2000V AC |
Range selection | Input - 100Ω - 10kΩ, output 4… 20mA |
Double Output | None |
Power | DC |
Working Temperature | - 40 to + 80 ° C |
Montage | On a DIN rail |
Dimensions | 25x41x97mm |
