Input types: thermocouple - K, E, J, T, B, R, S, N
Types of outputs: current 4… 20mA
Possibility to make the range of inputs / outputs on special order.
Wire connection | M3 screw terminals |
---|---|
Separation | Input / Output / Power |
Dielectric Strength | For DC power: 2000V AC |
Range selection | Input - 100Ω - 10kΩ, output 4… 20mA |
Double Output | None |
Power | DC |
Working Temperature | - 40 to + 80 ° C |
Montage | On a DIN rail |
Dimensions | 25x41x97mm |
Sunteți interesat de acest produs? Aveți nevoie de informații suplimentare sau de prețuri individuale?
trebuie să fii logat
Input types: thermocouple - K, E, J, T, B, R, S, N
Types of outputs: current 4… 20mA
Possibility to make the range of inputs / outputs on special order.
Wire connection | M3 screw terminals |
---|---|
Separation | Input / Output / Power |
Dielectric Strength | For DC power: 2000V AC |
Range selection | Input - 100Ω - 10kΩ, output 4… 20mA |
Double Output | None |
Power | DC |
Working Temperature | - 40 to + 80 ° C |
Montage | On a DIN rail |
Dimensions | 25x41x97mm |
