Kinds of inputs: Thermocouple - K, E, J, T, B, R, S, N, U, L, P
Kinds of outputs: current or voltage with different ranges
Possibility to make a range of inputs / outputs on special request.
Connection wires | M3 screw terminals |
---|---|
Separation | Input / Output / Power |
Dielectric strength | DC: 2000V AC AC: 1500V AC |
Ranges selection | Programmable via PC |
Double out | None |
Power | AC / DC |
Working temperature | - 30 to + 60 ° C td> |
Mounting | DIN rail | Dimensions | 23x76x124mm |
