Dimensions
|
W44xH73xD90mm
|
Time ranges
|
It can be adjustable between 0-9.9 seconds and 0-99 hours.
|
Accuracy
|
±1%
|
Start
|
By start input
|
Output function
|
6 different timing functions can be selectable.
|
Output 1
|
1 relay 230V AC, 2A (for resistive load), NO+NC.
|
Output II
|
1 relay 230V AC, 2A (for resistive load), NO+NC.
|
Reset
|
By reset input |
Supply voltage
|
230V AC +10% -20%, 50/60Hz or 24V AC ±10%, 50/60Hz or optional 9-30V DC / 7-24V AC ±10% SMPS module.
|
Power consumption |
2VA
|
Ambient temperature
|
0... 50°C
|
Wiring
|
11 pins round socket
|
Weight |
215g
|
Type | Description |
---|---|
PTM232 | time relay, power supply 230 V AC |
PTM232-SM | time relay, power supply 9-30 VDC/7-24 VAC |
ERS11 | 11 pins round socket DIN assembled |
Dimensions
![]() |
Terminals
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
