Dimensions:
|
72x72 mm.
|
Display:
|
4 digits.
|
Easy to operate.
|
|
Selectable sensor type.
|
|
Unit selection:
|
°C, °F.
|
Supply:
|
230V AC lub9...30VDC/7...24VAC, 24AC ±10%
|
Power consumption:
|
Max 7VA
|
Data retention:
|
EEPROM (minimum 10 years)
|
Assembly:
|
Panel
|
Dimensions:
|
72x72x97mm
|
Ambient/storage temperature
|
0..50°C/-25..70°C
|
Rated pollution degree
|
According to EN 60529 Front panel : IP65
Rear panel : IP20 |
Sensor type | Temperature range [°C] | Accuracy |
---|---|---|
Thermocouple J (Fe-CuNi) | 0..600 | ± 0,2% ±1 digit |
Thermocouple K (NiCr-Ni) | 0..1200 | |
Thermocouple T (Cu-CuNi) | 0..400 | |
Thermocouple S (Pt10Rh-Pt) | 0..1600 | |
Thermocouple R (Pt13Rh-Pt) | 0..1600 | |
Pt100 | -200..600 |
Type | Power supply |
---|---|
ETI741 | 230V AC |
ETI741+SM | 9...30 V DC-7...24 V AC |
