Application:
- electrical devices, which need insulation class F and H,
- motors for hermetic sets,
- magnetic sheets gluing. .
Main characteristics:
- this impregnated lacquer, straw colour, made on the epoxide resin base, has great adhesion preferences, which allow for good glueing enamel windings and transformers.
- has great resistance for diluent
- lacquer E 524 TS is not toxic, and completely resistant FREON 22
- it also has certification for its resistance for piralen,
- it is adequate for enamel wires class B,
Impregnation:
- preliminary object heat up to temperature 40 4 50°C
- object immersion until there are no air blisters.
- dripping for a short period of time depending on the object weight.
Polymerisation:
- 1 hour @ 110°C (object temperature),
- temperature rise up to 160°C,
- keeping temperature 160°C for 1,5 - 4 hours. (depends on object).
If operation conditions require this, it is possible to act in two phases:
- after impregnation and dipping, first drying at 110C is to evaporate diluent and preliminary polymerisation.
- Polymerisation can be made later, even after some storage time.
Storage conditions:
12 months in original and closed package, far away from the sun and heat source.
Packing:
- in containers 1, 5, 30 l or in barrels 200l.
Thermal indicator E 524 TS on the screw coil.
- ASTM D 3145.
enamel wire 300 HAX ThermkO.
|
Thermal indicator E 524 TS for twist
- ASTM D 3245.
enamel wire 300 HAX Thermk O.
|
![]() |
![]() |
