One component - for insulation class H 180°C.
Application:
-static and whirling electro technical material
Main characteristic:
LacquerP721:
- it is a non saturated polyester resin with reactive one component monomer.
- it is in liquid condensation, as one component.
- it is easy to use
- it has good thermal resistance
Material impregnation:
By immersion, vacuum.
Polymerisation:
It is not necessary to remove diluent. Polymerization lasts 4 hour at 150C temperature.
Storage conditions:
6 months in original and closed package, far away from the sun and heat source.
Packing:
Containers 1-5, 30 and 200 l
Hygiene and protection:
It doesn't contain styrene.
Lacquer | Standard | P721 |
---|---|---|
Chemical origins | Non saturated polyester | |
thermal class | IEC216 | [H] 180°C |
viscosity 23°C CPE 6: | ISO 2431 | 60 s |
density @ 23°C | NSEG 00 | 500 mPas |
density @ 20°C | NFT 30020 | 1.102 |
[ISO 2811] | >61°C | |
Colour: | natural[transparent yellow] | |
Gelation time 121°C± 1°C | NSEG 0012 | 8 min. ± 1 min 30 s |
Polymerisation | 4 h. @ 150°C | |
sintering[ after polymerisation 4H/150°C] | CEI 1033screw twist [helical coil]CEI 455 | 20°C>10daNprzy 180°C>2daN |
Break down voltage [after polymerisation 4H/150°C] | 500V | |
