Input types: universal, mA DC, mV DC, µA, V DC, mA AC, A AC, mV AC, V AC, thermocouple, sensor (Pt 50, Pt 100, Pt1000 ..., Ni, Cu), frequency (pulse), resistance (potentiometric), pneumatic.
Types of outputs: mA DC, mV DC, VDC, frequency (pulse)
Possibility to make a range of inputs / outputs on a special request.
Wire connection | < td style = "padding-left: 20px"> M3 screw terminals|
---|---|
Separation | Input / Output / Power |
Dielectric strength | DC: 2000V AC AC: 1500V AC |
Ranges selection | To be ordered or programmed One Step Cal / PC |
Double output | None |
Power | AC / DC |
Operating Temperature | - 30 to + 60 ° C |
Editing | On a DIN rail |
Dimensions | 23x76x124mm td > |
Да ли вас занима овај производ? Да ли су вам потребне додатне информације или појединачне цене?
морате бити пријављени
Input types: universal, mA DC, mV DC, µA, V DC, mA AC, A AC, mV AC, V AC, thermocouple, sensor (Pt 50, Pt 100, Pt1000 ..., Ni, Cu), frequency (pulse), resistance (potentiometric), pneumatic.
Types of outputs: mA DC, mV DC, VDC, frequency (pulse)
Possibility to make a range of inputs / outputs on a special request.
Wire connection | < td style = "padding-left: 20px"> M3 screw terminals|
---|---|
Separation | Input / Output / Power |
Dielectric strength | DC: 2000V AC AC: 1500V AC |
Ranges selection | To be ordered or programmed One Step Cal / PC |
Double output | None |
Power | AC / DC |
Operating Temperature | - 30 to + 60 ° C |
Editing | On a DIN rail |
Dimensions | 23x76x124mm td > |
