Фотографије су само у информативне сврхе. Погледајте спецификацију производа
please use latin characters
Cooling power range | 6000 - 10900 W |
Casing | Steel, covered with polyester, colour RAL 7035, casing is removable. |
Compressor | Hermetically closed compressor with thermal protection. |
Cooling circuit | Stub pipe for cooling liquid refill, filter, high pressure switch, cooling liquid R134a. |
Evaporator | Plate heat exchanger with icing protection and flow sensor. |
Condenser | High efficient, spiral exchanger with ribs, protected with steel net. |
Axial fan | Protected thermally and with metal net. |
Hydraulic circuit | Consist of electric pump, plastic water container, valve, manometer 0-10 bar. Evaporator is protected with flow sensor. |
Temperature control | Done by the microprocessor controller TX200, which allows for water temperature control as well as setting of the alarms, lights and turning device on/off. |
Dimensions
Technical data
Type | TCW 56 | TCW 70 | TCW 91 | TCW A0 |
---|---|---|---|---|
Nominal cooling power [W] | 6000 | 8100 | 9200 | 10900 |
Ambient temperature range [°C] | +15 ÷ +45 | |||
Water temperature range [°C] | +8 ÷ +25 | |||
Cooling liquid | R134a | |||
Power supply [V/Hz] | 400 3f / 50 | |||
Power [W] | 4030 | 4130 | 4430 | 4830 |
Pump | ||||
Water flow [l/min] | 17,0 / 50,0 | 23,0 / 50,0 | 26,0 / 50,0 | 32,0 / 50,0 |
Water pressure [bar] | 3,0 | 2,8 | 2,5 | 2,3 |
Container capacity [l] | 60,0 | |||
Water terminal [BPS] |
¾" | |||
Weight [kg] | 152,0 | 154,0 | 157,0 | 160,0 |
