M2DYH2 - поточний цикл живлення для сигналів HART

M2DYH2 is a current loop power supply.

Features

• Power supply for HART signals
• Open circuit detection
• It powers the 4… 20mA DC current loop
• Mounting socket for each model - allows easy assembly / disassembly and quick conversion of converters without the need to interfere with the wiring
• Electrically isolates the output signal from the power input < / li>
• Provides galvanic isolation
• Short-circuit protection
• Output power - 24 V DC
• AC / DC power



Input: 4… 20mA
Output: 4… 20mA




Wire connection	M3 screw terminals
Separation	Input / Output / Power
Dielectric Strength	DC: 2000V AC AC: 1500V AC
Ranges selection	None
Double Exit	None
Power	AC / DC < / td>
Operating Temperature	- 5 to + 55 ° C
Mounting	DIN rail
Dimensions	23x76x124mm
